Wheel excavator Hengte HT175W

breadcrab

Product catalog Earthmoving equipment Wheeled excavator Wheel excavator Hengte HT175W

Brand: Hengte

Main features:

Machine weight, kg15920

Bucket capacity, m³0.7

Overall Length, mm7540

Bucket digging power, kN92.2

Characteristics

Main Technical Specifications

Engine model QSB5.9-C180

Engine power, kW/rpm 132/2200

Machine weight, kg 15920

Bucket capacity, m³ 0.7

Overall Dimensions

Overall Length, mm 7540

Overall Width, mm 2550

Total height during transportation, mm 3740

Tail turning radius, mm 2400

Wheel track, mm 2670

Boom length, mm 4600

Bucket height, mm 590

Bucket lifiting height, mm 450

Turning Platform Height, mm 2670

Wheelbase, mm 1900

Bucket rod length, mm 2500

Bucket Width, mm 2700

Ground clearance, mm 100

Working Range

Maximum digging radius, mm 8550

Maximum digging height, mm 9022

Maximum unloading height, mm 6260

Maximum digging depth, mm 5025

Hydraulic system pressure, MPa 32

Bucket digging power, kN 92.2

Bucket capacity, m³ 0.7

Hydraulic fuel tank capacity, L 180

Hydraulic system flow, L/min 2*160

Rotation speed, rpm 13-14

Fuel tank capacity, L 220

Bucket rod digging force, kN 59.7

Gradeability, % 60

Max. Traveling speed, km/h 30
